Today I got my shipment from power jack and it wasn't what I expected
It's runs fairly well but is very simple
I think it's a 4k max unit like the 8000W PJ unit.
The transformer has no tag on it but appears to be the same core as my other unit
It has 3 caps on the power board
The fets are RUH1H150R 100v 120A
That makes them capable of 50% more current than the RU7088R FETs in my 24v unit
Anyone know what I have here?
Anyone know what I have here?
Yeah, a Power Jack inverter with a different sticker on top 😉.
Power Jack actually makes several rebranded inverters. They offered to rebrand something for us but we decided to go the all custom route instead. I find it odd that they dont at least print out a brand new sticker. Would be curious to see the inside of it.
Anyone know what I have here?
I am confused that you ordered a 12000w PJ inverter and was sent a Blue Energy 8000w inveter made by PJ . This has to be a custom inverter that someone return to Walnut . The largest is 3500w by Blue Energy on their wsb site . The 8000w inverter NOT AMG will probably do 4000w and will not have a ASL2.0 transformer .
<a href="/monthly_2022_07/1971092684_Screenshot(640495).png.072701482dfdef56b78bab4783a4a2ff.png" class="ipsAttachLink ipsAttachLink_image"><img data-fileid="1548" src="//forums.genetrysolar.com/applications/core/interface/js/spacer.png" data-src="/monthly_2022_07/562881051_Screenshot(640495).thumb.png.f9cb0fac7186fa71459e3bf6fbfca775.png" data-ratio="56.2" width="1000" class="ipsImage ipsImage_thumbnailed" alt="Screenshot (640495).png">
It is AMG
I am confused that you ordered a 12000w PJ inverter and was sent a Blue Energy 8000w inveter made by PJ .
Hey, it would be nice if you would get your facts straight before just posting.
- That's not a Blue Energy inverter.
- Blue Energy is not made by PJ
- It is not a custom inverter. It's a newer AMG-series PJ rebranded with a different sticker on top.
- The sticker doesn't even say Blue Energy. It says Plus Energy WccSolar
Can't find much on Plus Energy WccSolar, but I did find this Spanish webpage, which clearly indicates that it's made by PJ: https://hiperchino.com/articulo/B079YW4JJZ/plusenergy-wccsolar-inverter
and of course, there's the "WccSolar" website, which the inverters are unabashedly relabeled PJs: https://www.wccsolar.net/product-page/inversor-solar-8000w-48v-onda-pura-cargador-120a?lang=en
It apparently has 3 capacitors, to my 2, and 120A mosfets.
Hey, it would be nice if you would get your facts straight before just posting.
I saw Energy and look up Blue Energy . He was sent a 8000w WccSolar AMG inverter . Maybe it has a ASL4.0 transformer but why no label ? He can probably return it . and get full refund ?
It apparently has 3 capacitors, to my 2, and 120A mosfets
His mainboard with 3 capacitor is probably like the mini mainboard in the 20kw PJ and has 6 FETs on each mosboard ? This 8000w WccSolar may do 4000kw ?
It apparently has 3 capacitors, to my 2, and 120A mosfets
The FETs are are different value, and can handle a higher wattage? Can additional capacitors be added by an end user to a PJ mainboard?
The FETs are are different value, and can handle a higher wattage? Can additional capacitors be added by an end user to a PJ mainboard?
Your mainboard can only have 2 capacitors and 4 FETs per mainboard I think . You can email Helen for the 20kw mini mainboard with 6 FETs and 4 capacitors . The cost of 185 dollars and maybe more now for a complete mainboard is probably not what you want to do .
19 minutes ago, dickson said:The FETs are are different value, and can handle a higher wattage? Can additional capacitors be added by an end user to a PJ mainboard?
Your mainboard can only have 2 capacitors and 4 FETs per mainboard I think . You can email Helen for the 20kw mini mainboard with 6 FETs and 4 capacitors . The cost of 185 dollars and maybe more now for a complete mainboard is probably not what you want to do .
There are circles printed on the mainboard pcb that indicate where additional caps could go. You can see one in this photo. I think I have 4 banks of 6 FET's. I don't know the value of them.
//content.invisioncic.com/g308908/monthly_2022_07/IMG_20220126_112936.thumb.jpg.f3c6a898df1edb075cbb940c0196f3db.jpg
There are circles printed on the mainboard pcb that indicate where additional caps could go. You can see one in this photo. I think I have 4 banks of 6 FET's. I don't know the value of them.
The mainboard is the same one in the 20kw PJ with 6 FETs mosboard . You can solder 2 more capacitors to the mainboard .
Label on the box
The main board has spots for 4 caps 3 installed
6 FETs per bank
High speed fan
The box says it's an ASL2
